Protecting against rogue devices in openSUSE with Full Disk Encryption

openSUSE have now multiple ways to configure a Full Disk Encryption (FDE) installation. A very secure and easy way (YaST2) of doing this is via user space tools, as we described multiple times (like here, here, or here). This solution is based on the systemd tool-set like systemd-cryptenroll, systemd-pcrlock and systemd-cryptsetup, among other, orchestrated by the in-house sdbootutil script.

One of the main advantages of using this systemd approach is the possibility of integrating multiple authentication methods. Together with the traditional password, asked at boot time during the initrd stage, we can now unlock the system using a certificate, a TPM2, or a FIDO2 key. We can mix some of them creating multiple LUKS2 key slots, and use, for example, a TPM2 to unlock the device in a unattended fashion and a FIDO2 key as a recovery mechanism.

Honestly, the TPM2, and the TPM2+PIN variation, are the most relevant ones for the user. As described in the other posts, the TPM2 is a (some times virtual) device that can attest the health of our system using a mechanism known as measured boot.

The tl; dr version of this is that each stage of the boot process, starting from the firmware, will load and “measure” the next stage before delegating the execution on it. For example, this means that there is a moment in the latest stages of the boot process where the UEFI firmware will load from the disk the boot loader into memory. This can be the shim, systemd-boot or grub2-bls. It will calculate a hash value (usually SHA256) and will command to the TPM2 an “extend” operation for one of the internal register (PCR).

The extension is a cryptographic computation that is very easy to calculate, but impossible to replicate. It is done to one of those internal registers (PCR) and consist of calculating the hash (again SHA256) of the old value of the PCR together with the hash of the component that we are measuring. This new value will replace the current PCR value, as is the only way to change those registers. The security property resides in that it is cryptographically impossible to force the write of a desired value on one of those PCRs, but very easy to calculate the final value.

So this means that if all the components of the boot chain process are measured (all the stages in the UEFI firmware, the firmware configuration, the boot loader, the command line, the kernel and even the initrd), the final PCRs values can be compared with our expectations, and discover if the system has been booted with a good known software and configuration, allowing us to instantly known if some component in the boot chain has been hacked or modified with out consent.

That is a powerful property to have, but what is more interesting is that we can have secrets that can only be open in case that we are in one of those good or recognized states. We can, for example, cipher (seal) the key that open an encrypted disk using the TPM2, together with a policy that will decipher (unseal) the same key only, and only if we are using the same TPM2 and the PCR values are on a list of expected ones. Those policies can be very complicated, and can include extra passwords, certificates or other checks that will be validated before the TPM2 can unseal the key.

With a mechanism like this in place, thanks to the systemd tools, we can now avoid entering the password to unlock the encrypted disk if the system is in a healthy state. Healthy in the sense that we cryptographically guarantee that the code and configurations used during the boot process are the expected one, and no one entered init=/bin/bash in our kernel command line, or replaced the kernel or initrd with a vulnerable one, for example.

With the integration that we made of this model in openSUSE, we can make updates of the system, including the boot loader or the kernel, and sdbootutil will transparently generate new predictions of expected PCR values that are now considered safe. This imply an update of the TPM2 policy, that will be taken into consideration for the next boot, so the automatic unlock will succeed. If something goes wrong and the expected PCR values are not meet, the user will need to enter the password that is stored in a different LUKS2 key slot to open the device, to audit the system and validate it.

The fault in the design

Using a TPM2 as described before is a clear increase in the security level, but it is not the final answer. Security is always asymptotic approximation.

Some years ago a physical attack was described for the Windows BitLocker FDE solution. BitLocker is also using the TPM2 in a similar way that was described before, but was not using encrypted session to communicate with the device. Intercepting the SPI bus was shown possible to recover the password that unlock the disk. systemd learned from that and used encrypted sessions early, but this attack can also be avoided if the policy used to unseal the key was also demanding a PIN or password that must be entered by the user. Now the TPM2 can only unseal the secret if the PCRs are in the correct state and the provided password is the correct one. Should be noted that AFAIK the SPI sniffing can work with Clevis.

But more recently a second attack was made public that fully affect the original proposal, and does not requires the sophistication of the original one. (Disclosure: the attack was also internally described independently months before and some counter measurements was put in place much early)

The article describes how that attack can be done checking in the initrd the filesystem UUID used to mount the encrypted device. This information is inside the /etc/crypttab stored in the initrd, that will do something like this:

systemd-cryptsetup attach cr_root /dev/disk/by-uuid/$UUID 'none' 'tpm2-device=auto'

If the expected firmware, configuration files, kernel and initrd are used during the boot process then the TPM2’s PCRs registers will have values that match the policy that unlock the device and the sealed key can be now unsealed by the TPM2, the disk will be unlocked, the switch root will succeed and the boot process will continue in the rootfs.

But what if the original drive is replaced by one that has the same UUID (it is a public information after all) that is also encrypted? Then the PCRs will be in the same correct state. Note that in measure boot is the previous stage the one that measures the next one before delegating the execution. Then systemd-cryptsetup will try to use the TPM2 to unlock the device using the key successfully unsealed by the TPM2 and … will fail to open it, of course. The rogue device maybe have a TPM2 key slot in the LUKS2 header, but for sure cannot be open with this TPM2 nor with the secret password.

In this situation systemd-cryptsetup will ask for the password to unlock the device, and the attacker can enter one that this time will open the rogue device. The switch root will happen but now it will continue the boot process in the fake rootfs, and a program stored there can make questions to the TPM2, that still contains the good PCR values. One of the questions can be the unseal of the secret key using the current policy. And this time (as was done before), the TPM2 will agree to deliver the secret to the bad program. Game over.

There are solutions for this attack, of course.

One is again to use TPM2+PIN instead of TPM2, the same solution for the sniffing attack. In this case the first systemd-cryptsetup call will fail and a password will be asked to unlock the device. But now the bad program cannot ask to the TPM2 to unseal the device using the current policy. The PCR values will match, but the policy also requires the enter of a secret PIN or password known by the real user, and without it the unseal will fail and the key will be keep safe.

Another solution is somehow invalidate the policy, extending some of the PCRs involved before the switch root, so the policy cannot be applied anymore after that. This can be done automatically by systemd-cryptsetup using the measure-pcr=yes in /etc/crypttab. With this option PCR15 will be extended using the volume key, a secret that can only be extracted knowing some of the device keys. For this solution to work, PCR15 needs to be included in the current policy, with an expected value of 0x000..00, the default one. Once the rogue device is open by the hacker provided password, PCR15 will be automatically extended and the value will be different from 0x000..00, invalidating the policy before the switch root.

That is a good solution, but not for us. In the daily situation the user will need to update the system, and a new policy needs to be calculated to replace the old one (for example when the kernel is updated). Because with systemd-pcrlock the policy is stored in the TPM2 in one of the Non Volatile RAM slots (NVIndex), we need to protect it somehow, so it cannot be replaced by other process. For that systemd is storing a secret key (recovery PIN) in a different NVIndex that is sealed by the same policy! If the key cannot be automatically recovered, because the policy does not apply anymore, then the recovery PIN will be asked to the user, making the update process a bit unpleasant if the policy is always invalidated.

Finally, another way to address the issue is to stop the boot process if we detect that the device is not the expected one. We can think of a new service, living in initrd that is executed in the very last moment, just before the switch root, that can stop the boot process (maybe halting the system) if the device that stores the rootfs is not the expected one.

For this, PCR15 is still a good solution. It contains the measurement of a secret (volume key) that can only be known by the real user, and cannot be replicated by the attacker. Ideally we can create a prediction for PCR15 and make this service to compare the effective value with the expected one, and if they are different then it can stop the boot process.

This is what the measure-pcr-validator service from sdbootutil is doing. sdbootutil first generates a prediction for all the encrypted devices that are opened during the initrd, and check that the correct tag is present in /etc/crypttab. To be able to access the volume key, the tool needs the root password, so this prediction is only update when it is really necessary, like for example when a new encrypted device is added. This prediction is signed by a private key stored in the host, as an extra security measurement, but because the public key is also stored in the ESP it is honestly not adding too much.

An extra service (measure-pcr-generator) will put some order on how the encrypted devices are opened, as this order is critical to produce a single possible PCR15 value. If we have one single device the order of measurements is not relevant, but if when have three (rootfs, /home, and swap, for example) we can have six possible and valid different values for PCR15.

The last step is that the dracut-pcr-signature service in the initrd will import from the ESP the prediction, the signature and the public key, so measure-pcr-validator can check the signature and compare the PCR value.

And that is all!

This approach is also kind of similar to what the new systemd-validatefs is doing, but for a file system level.
